High-strength polypropylene staple fiber needle-punched geotextile
Due to the use of high-strength polypropylene short fibers and the use of a needle punching process to tightly entangle the fibers, the geotextile has high tensile strength and tear strength and can withstand greater external forces.
Tel : +86 15563581786
Whatsapp : +86 15563581786
Email :info@dingrunmaterial.com

Product Description

High-strength polypropylene staple fiber needle-punched geotextile has various application scenarios:

In port engineering:

Used to reinforce the foundation of dock yards and improve load-bearing capacity.

As a protective layer for breakwaters, it resists the impact of waves.

In mining engineering:

Used for reinforcement and anti-seepage of tailings dams to ensure the safety of tailings ponds.

Protect open-pit mine slopes to reduce ore slippage and soil erosion.

In tunnel projects:

As the waterproof layer and reinforcing layer of tunnel lining, it improves the waterproof performance and structural strength of the tunnel.

In artificial lakes and landscape projects:

Used for anti-seepage and reinforcement of lake bottoms and revetments to maintain the stability of water bodies.

        LtemUnit Value
1002003004005006008001000
Mass per unitg/m2100(1±5%)200(1±6%)300(1±6%)400(1±6%)500(1±6%)600(1±6%)800(1±6%)1000(1±6%)
Grip strength(MD and TD)N≥450≥900≥1250≥1600≥2000≥2400≥3000≥3600
Grip extension(MD and TD)%50~9050~100
Trapezoidal tear strength(MD and TD)N≥175≥350≥425≥500≥580≥650≥800≥950
CBR bursting strengthKN≥1.25≥2.5≥3.5≥4.3≥5.3≥6.2≥7.1≥8.0
Breaking strength(MD and TD)KN≥5.5≥11≥16≥22≥28≥34≥45≥55
Elongation at break(MD and TD)%40~6550~80
piercing forceN≥220≥430≥665≥900≥1200≥1430≥1900≥2350
thicknessmm1.4~1.71.8~2.22.4~2.83.0~3.53.6~4.04.0~4.44.8~5.25.6~6.0
Peel strengthN/5 cm≥80≥100
Anti-acid, alkaline(Polypropylene material)%Breaking strength retention rate≥90%;Elongation at break retention rate90%
UV resistance strong retention rate%≥80
Equivalent aperture(Dry sieve)mm≤0.1
vertical permeability coefficientcm/s≤0.2
